In the high-speed signal testing process, an accurate and stable test fixture is crucial for ensuring precise test results.
What can iST do for you
iST not only offers high-speed signal testing services but also focuses on providing test fixtures for clients, especially in the fields of PCIe 5.0 and Ethernet testing. We offer and sell test fixtures that meet customer requirements, providing a complete solution from planning, design, and verification to production. This not only helps clients improve testing efficiency and shorten development cycles but also prevents testing errors caused by poor fixture design, ensuring high performance and reliability of their products.
- PCIe5.0 Test Fixture non-std Formfactors：
These test fixtures can be used to test different shapes and types of device interfaces, such as U.2, U.3, M.2, EDSFF, and OCP, which are common standards for high-performance storage or networking device interfaces. - Ethernet ISI Channel Evaluation Board:：
- For 56G Baud Channel
- 28 Multi-Pairs
- 28G Baud Compatible
- Customization Test Fixture：
Design custom test fixtures according to customer requirements, providing end-to-end services from planning, design, and testing verification to production, ensuring the effectiveness of testing equipment and compliance with specific requirements.
- PCIe5.0 Test Fixture non-std Formfactors：
Case Study
● U.2 CBB+CLB
- Signal Integrity Board for U.2(SFF-8693) Physical Layer Conformance.
- Support PCIe 5.0 (32GT/s), U.2 CBB and CLB for both receivers and transmitters calibration
- MMPX connectors are 100% compatible with PCI- SIG CEM ISI board.
● U.3 CBB+CLB
- Signal Integrity Board for U.3(SFF-TA- 1001) Physical Layer Conformance.
- Support PCIe 5.0 (32GT/s), U.3 CBB and CLB for both receivers and transmitters calibration
- MMPX connectors are 100% compatible with PCI- SIG CEM ISI board.
● M.2 CBB+CLB1+CLB2
- Signal Integrity Board for M.2 Physical Layer Conformance.
- Support PCIe 5.0 (32GT/s), M.2 CBB and CLB1 CLB2 for both receivers and transmitters calibration
- MMPX connectors are 100% compatible with PCI- SIG CEM ISI board
● EDSFF E1.S/E1.L CBB+CLB
- Signal Integrity Board for EDSFF(SFF-TA-1006, SFF-TA-1007) Physical Layer Conformance.
- Support PCIe 5.0 (32GT/s), EDSFF CBB and CLB for both receivers and transmitters calibration
- MMPX connectors are 100% compatible with PCI- SIG CEM ISI board
● OCP 3.0 CBB+CLB1+CLB2
- Signal Integrity Board for OCP Physical Layer Conformance.
- Support PCIe 5.0 (32GT/s), OCP CBB and CLB1 CLB2 for both receivers and transmitters calibration
- MMPX connectors are 100% compatible with PCI- SIG CEM ISI board
● Key Feature
For 56 GBaud Channel Emulation
- Use of 1.85 mm connector
- Design for 56 GBaud and 28 GBaud
- 28 differential channels
28 Multi-Pairs
- Loss Range - 4.8 dB to 31.3 dB in 28 pairs @ 26.56 GHz
- Pair length - 3.6 inch to 25.8 inch
28 GBaud Compatible
- Loss Range - 2.3 dB to 16.5 dB in 28 pairs @ 13.28 GHz
- Pair length - 3.6 inch to 25.8 inch
